PCBLion's Factory Tour
Built for precision, engineered for scale. Every workstation, process line, and quality checkpoint in PCBLion’s facility exists for one purpose — delivering boards that perform exactly as designed, every time.
SMT Workshop
PCBLion’s production floor operates under Lean Manufacturing principles with full ESD S20.20 static control compliance throughout every zone. A digitized Manufacturing Execution System tracks every board, component, and process step in real time, giving our production and quality teams complete visibility from material intake to finished goods.
PCB Fabrication
- Material Cutting & Barcode Tracking
- LDI Laser Direct Imaging (Orbotech)
- Vacuum Lamination & CNC Drilling
- XRF Plating Thickness Lab
PCBA Assembly
- Climate Controlled Warehouse
- 8 Automated SMT Lines (Yamaha/Fuji)
- 3D SPI & 3D AOI (Koh Young)
- Heller 10-Zone Nitrogen Reflow
Quality Lab
- X-Ray Void Analysis (Unicomp)
- TDR Impedance Lab (Polar)
- Reliability Testing (Thermal/Shock)
- Ionic Contamination (Rose Test)
37,000 m² Facility
PCB Fab (25,000 m²) and PCBA Assembly (12,000 m²) under one roof in Shenzhen. PCBLion operates 5 high-speed SMT lines capable of handling the most demanding assembly requirements in production today.
Paste Printing
GKG fully automatic printers paired with 3D SPI verify paste volume and placement accuracy before a single component is placed, eliminating the most common source of soldering defects at the source.
Component Placement
Yamaha YSM Series and Fuji mounters handle 01005 passives, 0.25mm pitch BGAs, and Package-on-Package components with the placement precision that high-density designs require.
Factory Environment
ESD Control
Conductive flooring, ionizers, and mandatory daily-tested wrist straps.
Climate Control
HVAC maintained at 23±2°C and 50±5% RH for optimal assembly.
Cleanroom
ISO Class 7 (Class 10,000) for medical and sterile assembly.
Ready to Ensure Automotive Reliability?
Partner with a manufacturer who understands zero-defect execution.
